User Guide • SC3-LARGO • CompactPCI
®
Serial CPU Board • Intel
®
Core
TM
5xxx Processor
The following table shows the factory settings of DS-P with different side boards mounted to the
SC3-LARGO:
Side Board DS-P PCIe Link Width
1 2 P-PCIE
None OFF OFF 4 Links x 1 Lane @
5GT/s
CCI-RAP OFF OFF 4 Links x 1 Lane @
5GT/s
CCK-MARIMBA ON OFF 1 Link x 4 Lanes @
5GT/s
CCL-CAPELLA ON OFF 1 Link x 4 Lanes @
5GT/s
PCS-BALLET OFF OFF 4 Links x 1 Lane @
5GT/s
SCS_TRUMPET OFF OFF 4 Links x 1 Lane @
5GT/s
© EKF -77- ekf.com
