Radio Remote Control of the Range E1
21
The stop function using the Radio Remote Control is only
available if the Radio Remote Control has been started.
Never leave the Transmitting Unit unattended so that
there is no doubt about the availability of the stop
function.
The “useful life”, as dened in international standards
and requirements, of the stop function is 20 years. in
any case, the Radio Remote Control should be replaced
before then. The “useful life” cannot be understood as
a warranty period.
After the STOP button is activated in the Transmitting
Unit, the Machine is no longer controlled by the Radio
Remote Control. The possible risks deriving from the
activation of the stop function should be evaluated both
by the Installer of the Radio Remote Control as well as
by the Manufacturer and the Owner of the Machine on
which the Radio Remote Control is installed. The User of
the Radio Remote Control should be adequately trained
in this regard.
8.3 Technical data of the range E1
Data Value
Operating range 150 m
Command response time (typical) <100 ms
Stop time (typical) 100 ms
Maximum stop time 0.5 s
Performance Level of the "stop
protection" according to ISO 13849-
1
Cat. 3 PL d
The technical data of the Receiving Unit of the E1 range is reported in
Part 2 and in the relative connection diagram.
8.4 Identication of the Radio Remote Control
The serial number (Serial Num.) uniquely identies the Radio Remote
Control.
The serial number can be found on the data plate of the Radio Remote
Control; each unit of the Radio Remote Control has its own data plate.
When sending a request regarding an Elca Radio Remote Control the
serial number (Serial Num.) of the Radio Remote Control itself must
be provided.
The Serial Num. should be reported in all communications with Elca
or with Persons who require information, spare parts or technical data
regarding the Radio Remote Control.
