10 Description of the Transmitting Unit
B
A
C
D
E
F
G
E1Radio remote system type:
AT E1-VETTATransmitting model:
Made in Italy
RADIOCONTROLS
TG23
TX module: MT32EL
Freq. range: 434.050-434.790 MHz
Protection degree: IP65
Internal battery: Li-ion 3.7 V 1100 mA
Transmitting power: < 10mW ERP
E100004Serial n° :
Manufact. : 2017
A Actuators (selectors, buttons, potentiometers)
B LED Check
C STOP mushroom button
D LED Charge
E Control LED
F Contacts for charging
G Rating plate
