Description of the Transmitting Unit
33
SIGNAL MEANING
The red LED [A] ashes slowly ( 1
ash/second).
The Radio Remote Control is working
correctly but the battery is low (run
time left less than 1 hour).
The red LED [A] is on for 1 second
then the system shuts down.
The access sequence has been
entered incorrectly.
The red LED [A] is on xed.
The Radio Remote Control indicates
the presence of an error (for
example: the STOP button is
pressed when the START button is
pressed).
The red LED [A] ashes rapidly.
Low battery (5 minutes of run time).
The Radio Remote Control might be
being disturbed or be at the limit
of its operating range or else in a
place with obstacles impeding the
transmission of the signals.
10.4.2 White LED [B]
1 2
3
4
The white LED [A], numbered from 1 to 4, can be used to have an
indication of the status of the inputs set up for this purpose on the
Receiving Unit.
