06/2016 - Art. Nr. 4200 1041 1103A8
Operation
Terminal allocation chart
* Terminal allocation depends on the design of the burner
Pin Terminal Description Connector
11
Display
X30
22
33
44
55
66
17
PC interface
X31
28
39
410
511
612
113
Servomotor gas
X32
214
315
416
517
618
119
Servomotor air*
X33
220
321
422
523
624
125
Servomotor fuel oil*
X34
226
327
428
529
630
Terminal
Display
PC interface
Gas
servomotor
Air
servomotor*
Fuel oil
servomotor*
1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6
Pin
Connector
