EWM1000plus EWM2000evo EWM3000new
QUICK GUIDE AND APPLIANCES LIST 36/176 599 72 40-80
2.13.1 Key for circuit diagram
Electric components Components on main board
1. Main board
2. Interference filter
3. Drain pump
4. Aqua control
5. ON/OFF switch (built into selector)
6. Anti-boiling pressure switch AE2
7. Door lock unit
8. Heating element
9. Anti-boiling pressure switch AE1
10. Anti-overflow pressure switch
11. Recirculation pump
12. Pre-wash solenoid valve
13. Wash solenoid valve
14. Bleach solenoid valve
15. Pilot lamp
16. Selector
17. Control/display board
18. Turbidity sensor
19. Flow meter
20. Analogic pressure switch
21. NTC temperature sensor
22. Thermal cut-out (motor)
23. Stator (motor)
24. Rotor (motor)
25. Tachometric generator (motor)
BEL_TY Bleach solenoid Triac
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Recirculation pump Triac
K1 Heating element relay
K4 Motor relay: clockwise rotation
K3 Motor relay: anti-clockwise rotation
K4 Motor relay: half field power supply (models with higher spin
than 1200 rpm)
MOTOR_TY Motor Triac
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
