Electrolux EWM1000 - Key for Circuit Diagram

EWM1000plus EWM2000evo EWM3000new
QUICK GUIDE AND APPLIANCES LIST 38/176 599 72 40-80
2.14.1 Key for circuit diagram
Electrical components on appliance Components on main board
1. Main board
2. Interference filter
3. Drain pump
4. ON/OFF switch (built into selector)
5. Aqua Control
6. Antiboiling pressure switch AE2
7. Door lock unit
8. Heating element
9. Antiboiling pressure switch AE1
10. Recirculation pump
11. Solenoid valve for prewash
12. Solenoid valve for wash
13. Solenoid valve for bleach
14. Door opening lamp
15. Selector
16. Control/display board
17. Flow meter
18. Analog pressure switch
19. Turbidity sensor
20. NTC temperature sensor
21. Tachometric generator (on motor)
22. Windings (on motor)
23. Inverter (for motor speed control)
BELV_TY Triac for solenoid valve for bleach dispenser
DOOR_TY Triac for door lock unit
DRAIN_TY Triac for drain pump
K1 Relay controlling heating element
K2 Safety relay
PWELV_TY Triac for solenoid valve for prewash
REC_TY Triac for recirculation pump
WELV_TY Triac for solenoid valve for wash
