3.15.1 Key to circuit diagram EWM25xx with Aqua Control
Electrical components on appliance Components on main board
1. LCD Module
2. Damper with weight sensor
3. Circuit board for weight sensor
4. Drum positioning sensor (DSP)
5. Flowmeter
6. Miscroswitch on door lock for drum light
7. Analogic pressure switch
8. Washing NTC temperature sensor
9. Solenoid valve for prewash
10. Solenoid valve for wash
11. Solenoid valve for bleach
12. Drum light
13. Thermal cut-out (circulation pump)
14. Pump circulation
15. Motor control board (FCV)
16. Interference filter
17. Instantaneous door interlock
18. Heating element (with thermal fuses)
19. Thermal cut-out (drain pump)
20. Drain pump
21. Aqua control (water leaks device)
22. Three-phase motor (induction)
23. Tachometric generator (motor)
24. Stator (motor
25. Main circuit board
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Bleach solenoid Triac
