ENV06 EWM11xx EWM21xx EWM25xx/35xx
QUICK GUIDE AND APPLIANCES LIST 55/176 599 72 40-80
3.9.1 Key to circuit diagram WM EWM2100
Electrical components on appliance Components on main board
1. Analogue pressure switch
2. NTC temperature sensor
3. Solenoid valve for prewash
4. Solenoid valve for wash
5. Solenoid valve for bleach
6. Thermal cut-out (circulation pump)
7. Pump circulation
8. Thermal cut-out (drain pump)
9. Drain pump
10. Stator (motor)
11. Rotor (motor)
12. Thermal cut-out (motor)
13. Tachometric generator (motor)
14. Interference filter
15. Instantaneous door interlock
16. Traditional door interlock
17. Heating element (with thermal fuses)
18. Motor with half field
19. Motor without half field
20. Circuit board
21. Drum sensor position (DSP)
22. Flowmeter
23. LCD module
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
K2 Motor relay: clockwise rotation
K3 Motor relay: anti-clockwise rotation
K4 Motor relay: half field power supply (some models)
MOTOR_TY Motor Triac
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Beach solenoid Triac
