ENV06 EWM11xx EWM21xx EWM25xx/35xx
QUICK GUIDE AND APPLIANCES LIST 73/176 599 72 40-80
3.19.1 Key to circuit diagram EWM35xx with Aqua Control
Electrical components on appliance Components on main board
1. Circuit board for LCD (TC1)
2. LCD Module
3. Damper with weight sensor
4. Circuit board for weight sensor
5. Drum positioning sensor (DSP)
6. Flowmeter
7. Miscroswitch on door lock for drum light
8. Analogic pressure switch
9. Washing NTC temperature sensor
10. Solenoid valve for prewash
11. Solenoid valve for wash
12. Solenoid valve for bleach
13. Drum light
14. Thermal cut-out (circulation pump)
15. Pump circulation
16. Motor control board (FCV)
17. Interference filter
18. Instantaneous door interlock
19. Heating element (with thermal fuses)
20. Thermal cut-out (drain pump)
21. Drain pump
22. Aqua control (water leaks device)
23. Three-phase motor (induction)
24. Tachometric generator (motor)
25. Stator (motor
26. Main circuit board
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Bleach solenoid Triac
