ENV06 EWM11xx EWM21xx EWM25xx/35xx
QUICK GUIDE AND APPLIANCES LIST 71/176 599 72 40-80
3.18.1 Key to circuit diagram EWM25xx WD without aqua control
Electrical components on appliance Components on main board
1. LCD Module
2. Flowmeter
3. Analogue pressure switch
4. NTC temperature sensor
5. Solenoid valve for prewash
6. Solenoid valve for wash
7. Condensation solenoid valve
8. Thermal cut-out (circulation pump)
9. Pump circulation
10. Thermal cut-out (drain pump)
11. Drain pump
12. Aqua Control (water leaks device)
13. Tachometric generator (motor
14. Stator (motor)
15. Induction motor
16. Interference filter
17. Instantaneous door interlock
18. Traditional door interlock
19. Heating element (with thermal fuses)
20. Humidity temperature sensor
21. Drying temperature sensor
22. Fan motor
23. Drying heaters
24. Thermostat with manual reset
25. Thermostat with automatic reset
26. Main circuit board
27. WD circuit board
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Circulation pumpTriac
K1 WD board supply relay
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Condensation solenoid Triac
