ENV06 EWM11xx EWM21xx EWM25xx/35xx
QUICK GUIDE AND APPLIANCES LIST 61/176 599 72 40-80
3.12.1 Key to circuit diagram WD with aqua control EWM2100
Electrical components on appliance Components on main board
1. Analogue pressure switch
2. NTC temperature sensor
1. Solenoid valve for prewash
2. Solenoid valve for wash
3. Condensation solenoid valve
4. Thermal cut-out (circulation pump)
5. Pump circulation
6. Thermal cut-out (drain pump)
7. Drain pump
8. Stator (motor)
9. Rotor (motor)
10. Thermal cut-out (motor)
11. Tachometric generator (motor)
12. Interference filter
13. Instantaneous door interlock
14. Traditional door interlock
15. Heating element (with thermal fuses)
16. Motor with half field
17. Motor without half field
18. Circuit board
19. Flowmeter
20. LCD Module
21. Humidity temperature sensor
22. Drying temperature sensor
23. Motor fan
24. Drying heating elements
25. Manually reset thermostat
26. Automatically reset thermostat
27. WD board
28. Aqua Control (water leaks device)
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
K2 Motor relay: clockwise rotation
K3 Motor relay: anti-clockwise rotation
K4 Motor relay: half field power supply (some models)
MOTOR_TY Motor Triac
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Beach solenoid Triac
