Elenos ETG300 - Parts List

Use and maintenance manual
Page 101
Engineering Department PHONE: +39 0532 829 965 - FAX: +39 0532 829 177
E-Mail: support@elenos.com
5. ELECTRICAL SCHEMATICS - 5.5. Driver
Ref. DescriptionParts list
C1 1n
C5 1n
C2 4n7
C3 4n7
C6 4n7
C30 4n7
C8 10n
C9 10n
C13 10n
C14 10n
C20 10n
C19 75pF
C11 75pF
C12 39pF
C15 43pF
C16 300pF
C23 300pF
C17 120pF
C22 47n
C21 47n
C24 4.7n
C25 4.7n
C27 10uF
C26 10uF
J1 INGRESSO max. +7dBm
J2 USCITA
L1 VK200
L10 VK200
L2 2u2
L9 2u2
L3 5sp1mmD6L8
L4 5sp1mmD8L5
L6 3sp1mmD6L6
L7 4sp1mmD6L6
L8 3sp1mmD6L9
L11 3sp1mmD6L8
Q1 BLF404
Q2 BLF244
R1 33K
R2 18
R3 18
R4 560
R5 560
R6 6K8
R7 47K
R8 680
R9 2.7
R10 100
R11 12K
R12 10
R13 47
R15 47
R16 47
R14 2.2
R18 10K
