5. ELECTRICAL SCHEMATICS - 5.3. Mother board
Ref. DescriptionParts list
CN1 HEADER 10 Connett. per flat cable 2X5
CN2 AMP MODU II Connett. AMP MODU 2pin p 2,54
CX1 47uF Cond. elettrolitico Case D
C25 47uF Cond. elettrolitico Case D
C30 47uF Cond. elettrolitico Case D
C33 47uF Cond. elettrolitico Case D
CX10 22uF 25V (montato volante)
C1 1nF Cond. ceramico SMT 0805
C10 1nF Cond. ceramico SMT 0805
C11 1nF Cond. ceramico SMT 0805
C14 1nF Cond. ceramico SMT 0805
C18 1nF Cond. ceramico SMT 0805
C21 1nF Cond. ceramico SMT 0805
C22 1nF Cond. ceramico SMT 0805
C41 1nF Cond. ceramico SMT 0805
C139 1nF Cond. ceramico SMT 0805
C147 1nF Cond. ceramico SMT 0805
C149 1nF Cond. ceramico SMT 0805
C2 47uF Cond. tantalio Case 3528
C3 4.7nF Cond. ceramico SMT 0805
C5 4.7nF Cond. ceramico SMT 0805
C6 4.7nF Cond. ceramico SMT 0805
C9 4.7nF Cond. ceramico SMT 0805
C12 4.7nF Cond. ceramico SMT 0805
C13 4.7nF Cond. ceramico SMT 0805
C19 4.7nF Cond. ceramico SMT 0805
C23 4.7nF Cond. ceramico SMT 0805
C24 4.7nF Cond. ceramico SMT 0805
C26 4.7nF Cond. ceramico SMT 0805
C27 4.7nF Cond. ceramico SMT 0805
C28 4.7nF Cond. ceramico SMT 0805
C29 4.7nF Cond. ceramico SMT 0805
C31 4.7nF Cond. ceramico SMT 0805
C32 4.7nF Cond. ceramico SMT 0805
C34 4.7nF Cond. ceramico SMT 0805
C35 4.7nF Cond. ceramico SMT 0805
C40 4.7nF Cond. ceramico SMT 0805
C157 4.7nF Cond. ceramico SMT 0805
C158 4.7nF Cond. ceramico SMT 0805
C152 220nF Cond. ceramico SMT 0805
C4 220nF Cond. ceramico SMT 0805
C7 100nF Cond. ceramico SMT 0805
C15 100nF Cond. ceramico SMT 0805
C17 100nF Cond. ceramico SMT 0805
C20 100nF Cond. ceramico SMT 0805
C42 100nF Cond. ceramico SMT 0805
C43 100nF Cond. ceramico SMT 0805
C44 100nF Cond. ceramico SMT 0805
C45 100nF Cond. ceramico SMT 0805
C47 100nF Cond. ceramico SMT 0805
C49 100nF Cond. ceramico SMT 0805
C50 100nF Cond. ceramico SMT 0805
C51 100nF Cond. ceramico SMT 0805
C52 100nF Cond. ceramico SMT 0805
C54 100nF Cond. ceramico SMT 0805
