Elenos ETG300 - Low-Pass Filter

Use and maintenance manual
Page 110
Engineering Department PHONE: +39 0532 829 965 - FAX: +39 0532 829 177
E-Mail: support@elenos.com
5. ELECTRICAL SCHEMATICS - 5.7. LP filter
ETG250-300
A.Giovannelli
A.Tomassini
2PCB0266B
Wednesday, November 15, 2000
33
LPF
1
Model:
Approved :
Proj. Engr. :
Website WWW.ELENOS.COM
Tel +39 0532 829965 Fax +39 0532 829177
Via G.Amendola 9 44028 Poggio Renatico (FE) Italy
ofSheet
Date:
Rev
Board Code:
Title:
RF in
L5
L1
L3 L4L2
CP2
9.1pF ATC 500V
CP13
9.1pF ATC 500V
CP7
27pF ATC 500V
CP1
18pF ATC 500V
CP3
27pF ATC 500V
CP10
27pF ATC 500V
CP6
27pF ATC 500V
CP9
27pF ATC 500V
CP12
18pF ATC 500V
CP4
27pF ATC 500V
