5. ELECTRICAL SCHEMATICS - 5.7. LP filter
Ref. DescriptionParts list
AR1 LMC7101
AR2 LMC7101
CL1 220pF
CP1 18pF ATC 500V
CP12 18pF ATC 500V
CP2 9.1pF ATC 500V
CP13 9.1pF ATC 500V
CP3 27pF ATC 500V
CP4 27pF ATC 500V
CP6 27pF ATC 500V
CP7 27pF ATC 500V
CP9 27pF ATC 500V
CP10 27pF ATC 500V
C6 4.7nF
C7 4.7nF
C15 4.7nF
C8 33pF
C9 33pF
C13 100nF
C14 100nF
C16 4.7nF
C17 100nF
C18 100nF
D1 HSMS 2850
D2 hsms2850
JP1 2PJ00134
L1 vedi note
L2 vedi note
L3 vedi note
L4 vedi note
L5 vedi note
NTC1 100K
NTCB1 100K
PR1 500
PR2 500
R3 500
R4 500
R1 12K
R2 12K
R5C 100
R6 330
R5 330
R7 500 ohm
R9 2K2
R1B1 2K2
R10 47
R16 47
R11 27K
R12 220K
R13 220k
R14 100
R15 100
R3B1 27K
