Elenos ETG300 - Schematics 5.7.2.1. Directional Coupler

Use and maintenance manual
Page 108
Engineering Department PHONE: +39 0532 829 965 - FAX: +39 0532 829 177
E-Mail: support@elenos.com
5. ELECTRICAL SCHEMATICS - 5.7. LP filter
ETG250-300
A.Giovannelli
A.Tomassini
2PCB0266B
Wednesday, November 15, 2000
31
POWER PROBES
1
Model:
Approved :
Proj. Engr. :
Website WWW.ELENOS.COM
Tel +39 0532 829965 Fax +39 0532 829177
Via G.Amendola 9 44028 Poggio Renatico (FE) Italy
ofSheet
Date:
Rev
Board Code:
Title:
RF out
13
2
13
2
C8
33pF
R4500
R5C
100
D2
hsms2850
D1
HSMS 2850
R6
330
R5
330
R7
500 ohm
C9
33pF
R1
12K
R2
12K
C7
4.7nF
C6
4.7nF
CL1
220pF
R3 500
input1
input2
testina
RF SAMPLE
