5. ELECTRICAL SCHEMATICS - 5.3. Mother board
Ref. DescriptionParts list
C56 100nF Cond. ceramico SMT 0805
C59 100nF Cond. ceramico SMT 0805
C60 100nF Cond. ceramico SMT 0805
C61 100nF Cond. ceramico SMT 0805
C62 100nF Cond. ceramico SMT 0805
C64 100nF Cond. ceramico SMT 0805
C68 100nF Cond. ceramico SMT 0805
C69 100nF Cond. ceramico SMT 0805
C73 100nF Cond. ceramico SMT 0805
C74 100nF Cond. ceramico SMT 0805
C75 100nF Cond. ceramico SMT 0805
C76 100nF Cond. ceramico SMT 0805
C77 100nF Cond. ceramico SMT 0805
C78 100nF Cond. ceramico SMT 0805
C79 100nF Cond. ceramico SMT 0805
C80 100nF Cond. ceramico SMT 0805
C83 100nF Cond. ceramico SMT 0805
C84 100nF Cond. ceramico SMT 0805
C85 100nF Cond. ceramico SMT 0805
C91 100nF Cond. ceramico SMT 0805
C92 100nF Cond. ceramico SMT 0805
C95 100nF Cond. ceramico SMT 0805
C96 100nF Cond. ceramico SMT 0805
C97 100nF Cond. ceramico SMT 0805
C98 100nF Cond. ceramico SMT 0805
C99 100nF Cond. ceramico SMT 0805
C104 100nF Cond. ceramico SMT 0805
C105 100nF Cond. ceramico SMT 0805
C106 100nF Cond. ceramico SMT 0805
C108 100nF Cond. ceramico SMT 0805
C109 100nF Cond. ceramico SMT 0805
C113 100nF Cond. ceramico SMT 0805
C116 100nF Cond. ceramico SMT 0805
C121 100nF Cond. ceramico SMT 0805
C122 100nF Cond. ceramico SMT 0805
C124 100nF Cond. ceramico SMT 0805
C125 100nF Cond. ceramico SMT 0805
C127 100nF Cond. ceramico SMT 0805
C128 100nF Cond. ceramico SMT 0805
C135 100nF Cond. ceramico SMT 0805
C138 100nF Cond. ceramico SMT 0805
C140 100nF Cond. ceramico SMT 0805
C151 100nF Cond. ceramico SMT 0805
C153 100nF Cond. ceramico SMT 0805
C155 100nF Cond. ceramico SMT 0805
C185 100nF Cond. ceramico SMT 0805
C8 1uF Cond. poliestere SMT (NON MONTARE)
C16 22nF Cond. ceramico SMT 0805
C36 10uF Cond. elettrolitico SMT Case C
C38 10uF Cond. elettrolitico SMT Case C
C144 10uF Cond. elettrolitico SMT Case C
C150 10uF Cond. elettrolitico SMT Case C
C39 10uF Cond. elettrolitico Case C
C37 10uF Cond. elettrolitico Case C
C46 4n7 Cond. ceramico SMT 0805
