5. ELECTRICAL SCHEMATICS - 5.3. Mother board
Ref. DescriptionParts list
C48 4n7 Cond. ceramico SMT 0805
C58 4n7 Cond. ceramico SMT 0805
C63 4n7 Cond. ceramico SMT 0805
C67 4n7 Cond. ceramico SMT 0805
C72 4n7 Cond. ceramico SMT 0805
C53 22pF Cond. ceramico SMT 0805
C57 22pF Cond. ceramico SMT 0805
C55 10uF Cond elettrolitico SMT Case C
C86 10uF Cond elettrolitico SMT Case C
C87 10uF Cond elettrolitico SMT Case C
C88 10uF Cond elettrolitico SMT Case C
C89 10uF Cond elettrolitico SMT Case C
C65 68pF Cond. ceramico SMT 0805
C66 68pF Cond. ceramico SMT 0805
C70 68pF Cond. ceramico SMT 0805
C71 68pF Cond. ceramico SMT 0805
C81 470nF Cond elettrolitico SMT Case B
C82 10uF/25V Cond elettrolitico SMT Case C
C90 10uF/25V Cond elettrolitico SMT Case C
C93 4.7uF Cond. elettrolitico SMT Case B
C94 100pF Cond. ceramico SMT 0805
C100 100pF Cond. ceramico SMT 0805
C107 100pF Cond. ceramico SMT 0805
C101 10pF Cond. ceramico SMT 0805
C102 10pF Cond. ceramico SMT 0805
C114 10pF Cond. ceramico SMT 0805
C112 2.2nF Cond. poliestere SMT
C103 2.2nF Cond. poliestere SMT
C110 10nF Cond. poliestere SMT
C111 47uF Cond. tantalio SMT Case 3528
C115 220nF Cond. poliestere SMT
C119 4,7uF Cond. tantalio SMT Case 3528
C126 4,7uF Cond. tantalio SMT Case 3528
C120 10uF Cond. tantalio SMT Case 3528
C123 10uF NP Cond. elettrolitico SMT Case C
C129 100uF Cond. tantalio SMT Case 7343
C130 100uF Cond. tantalio SMT Case 7343
C132 100uF Cond. tantalio SMT Case 7343
C133 100uF Cond. tantalio SMT Case 7343
C134 100uF Cond. tantalio SMT Case 7343
C131 47uF Cond. tantalio SMT Case 7343
C136 22uF Cond. elettrolitico SMT Case C
C137 10nF Cond. ceramico SMT 0805
C141 1500uF Cond elettolitico Vert. 6,3V
C142 68uF Cond. tantalio SMT Case 7343
C143 47nF Cond. ceramico SMT 0805 (NON MONTARE)
C145 220pF Cond. ceramico SMT 0805
C146 100nF Cond. ceramico SMT 0805 (NON MONTARE)
C148 470uF Cond. elettrolitico passo 5,08
C154 27pF Cond. ceramico SMT 0805
C156 47uF Cond. elettrolitico SMT Case D
C159 4.7pF Cond. ceramico SMT 0805
C160 33uF Cond. elettrolitico SMT Case C
C161 4.7nF Cond. ceramico SMT ATC 0805 X7R472KL2AT
C162 4.7nF Cond. ceramico SMT ATC 0805 X7R472KL2AT
