5. ELECTRICAL SCHEMATICS - 5.2. Switching power supply
Ref. DescriptionParts list
C5 1uF Cond. Poliestere scatolino
C6 47uF Cond. Elettrolitico verticale105°
C7 1000uF Cond. Elettrolitico snap-in 85°
C8 1000uF Cond. Elettrolitico snap-in 85°
C9 1000uF Cond. Elettrolitico snap-in 85°
C10 1uF Cond. Poliestere scatolino
C11 100nF Cond. Ceramico multistrato
C12 100nF Cond. Ceramico multistrato
C13 1uF Cond. Ceramico multistrato
C14 100nF Cond. Ceramico multistrato
C15 1uF Cond. Ceramico multistrato
C16 47uF Cond. Elettrolitico verticale
C17 1uF Cond. Ceramico multistrato
C18 330pF Cond. Ceramico multistrato
C19 1nF Cond. Poliestere scatolino
C20 10nF Cond. Ceramico multistrato
C21 100nF Cond. Ceramico multistrato
C22 10uF Cond. Tantalio a goccia
C23 10pF Cond. Ceramico a disco
C24 100nF Cond. Ceramico multistrato
C25 100pF Cond. Ceramico multistrato
C26 100nF Cond. Ceramico multistrato
C27 1uF Cond. Ceramico multistrato
C28 100nF Cond. Ceramico multistrato
C29 100nF Cond. Ceramico multistrato
C30 2,2nF Cond. Ceramico multistrato
C31 100nF Cond. Ceramico multistrato
C32 100nF Cond. Ceramico multistrato
C33 2,2nF Cond. Ceramico alta tensione
C34 1uF Cond. Poliestere scatolino
C35 22uF Cond. Elettrolitico verticale 105°
C36 220uF Cond. Elettrolitico verticale 105°
C37 1uF Cond. Ceramico multistrato
C38 100nF Cond. Ceramico multistrato
C39 22nF Cond. Ceramico multistrato
C40 22nF Cond. Ceramico multistrato
C41 1uF Cond. Poliestere scatolino
C42
C43 100nF Cond. Ceramico multistrato
C44 1nF Cond. Ceramico multistrato
C45 100nF Cond. Ceramico multistrato
C46 100nF Cond. Ceramico multistrato
C47 1uF Cond. Ceramico multistrato
C48 100nF Cond. Ceramico multistrato
C49 100nF Cond. Ceramico multistrato
C50 220nF Cond. Ceramico multistrato
C51 100nF Cond. Poliestere scatolino
C52 330pF Cond. Ceramico multistrato
C53 4,7nF Cond. Ceramico multistrato
CX 1uF Cond. Poliestere scatolino
D1 1N4148 Diodo silicio
D2 ZPD5,6V Diodo zener
D3 BAT48 Diodo schottky
D4 BYV27-200 Fast recovery avalance diode
D5 1N4148 Diodo silicio
