TelevisGo Page 19/68
5.2.2 CONFIGURING THE DEVICE NETWORK
To set up a network of devices, go to:
Settings Interfaces Scan
To access this section, data logging must be suspended (see Data Logging section).
Now click the
icon. This page opens:
Page last update on: 7.39.34
Select all Deselect all Manage Interfaces
LAN Adapter
Interface
ID Address Fieldbus Discovery range
0
192.168.0.1
From
to
00
LanAdapter 00 14 14
Naming
Out of network
Discovery
View
12 34
A list of all available and previously defined interfaces is displayed (see the Defining Interfaces section) along with associated
settings (name, ID, address....).
Set the scan range using pop up menus 1, 2, 3 and 4.
The default ranges are: 00:00/14:14 for Micronet networks and 00:00/15:15 for Mixed networks.
To start scanning or to find network devices, click the
icon.
NOTE:
Scanning the full range can take a few minutes.
Likewise, it could take even longer if there are any unused addresses (the system makes more than one attempt when it doesn't
receive a reply) or if a Mixed network is being used.
On completion, the following window opens:
LAN Adapter
Interface
Interface
identifier
DevicesAddress
0 192.168.0.1 1
Address Description State
New0 02:00 0.00:00 ID 974LX02:00
A
B
Line A identifies the network scanned. Line B and subsequent lines list devices associated to the network.
The colour of each line has a specific meaning:
• GREEN: new device located in the network
• BLACK: existing network device
• GREY: device not located, part of previous network but possibly no longer present.
• RED: device for which TelevisGo has no internal driver.
On completion, click Save to save all data logged.
Click the
icon to go back a menu.
If you change page without saving, any changes made will be lost (the same as clicking Cancel).
IMPORTANT: in the following circumstances, a second scan must be performed:
• If one or more devices have been added
• If the drivers of one or more TelevisGo controllers have been updated.
• If you have enabled/disabled one or more controller resources by changing some parameters.
• A device changed alarm is displayed.
