Component Connector
Described
in Section Diagram
Main Feedback Cable
J3
3.5.5
Auxiliary Feedback (if needed)
J2
3.5.6
Digital Input Cable (if needed)
J5
3.5.6
Digital Output Cable (if needed)
J6
3.5.6
Communication Cables
(RS-232 and/or CANopen)
J1, J8, J9
3.5.8
1
PC for drive setup and tuning
Motor data sheet or manual
