1.1 Warnings
To avoid electric arcing and hazards to personnel and electrical
contacts, never connect/disconnect the servo drive while the power
source is on.
Power cables can carry a high voltage, even when the motor is not in
motion. Disconnect the Bassoon from all voltage sources before it is
opened for servicing.
The Bassoon servo drive contains grounding conduits for electric
current protection. Any disruption to these conduits may cause the
device to become “hot” (live) and dangerous.
After shutting off the power and removing the power source from
your equipment, wait at least 1 minute before touching or
disconnecting parts of the equipment that are normally loaded with
electrical charges (such as capacitors or contacts). Measuring the
electrical contact points with a meter before touching the equipment
is recommended.
1.2 Cautions
The Bassoon servo drive contains hot surfaces and electrically-charged
components during operation.
The maximum AC power supply connected to the instrument must
comply with the parameters outlined in this guide.
The Bassoon drive must be connected to an approved 24VDC
auxiliary power supply through a line that is separated from
hazardous line voltages using reinforced or double insulation in
accordance with approved safety standards.
The Bassoon X/230 series is designed to gets its power from a 30 ~
255 VAC single phase power source. It can be connected directly to
the line voltage. An isolation transformer is not needed.
Before switching on the Bassoon, verify that all safety precautions
have been observed and that the installation procedures in this manual
have been followed.
Bassoon Installation Guide Safety Information
MAN-BASIG (Ver 1.4)
