A.8.5 Resolver
Feature Details
Resolver format
Sine/Cosine
Differential
Input resistance Differential 2.49 kΩ
Resolution Programmable: 10 ~ 15 bits
Maximum electrical frequency
(RPS)
512 revolutions/sec
Resolver transfer ratio 0.5
Reference frequency 1/Ts (Ts = sample time in seconds)
Reference voltage Supplied by the Bassoon
Reference current
up to ±50 mA
A.8.6 Tachometer*
Feature Details
Tachometer format
Differential
Maximum operating differential
voltage for TAC1+, TAC1-
±20 V
Maximum absolute differential
input voltage for TAC1+, TAC1-
±25 V
Maximum operating differential
voltage for TAC2+, TAC2-
±50 V
Maximum absolute differential
input voltage for TAC2+, TAC2-
±60 V
Input resistance for TAC1+,
TAC1-
46 kΩ
Input resistance for TAC2+,
TAC2-
100 kΩ
Resolution 14 bit
* Only one Tachometer port can be used at a time (either TAC1+/TAC1- or
TAC2+/TAC2-).
TAC1+/TAC1- is used in applications with having a Tachometer of less than 20 V.
TAC2+/TAC2- is used in applications with having a Tachometer of between 20 V and
50 V.
Bassoon Installation Guide Technical Specifications
MAN-BASIG (Ver 1.4)
A-10
