Elmo Bassoon User Manual

A.3 General Specifications
Feature Units 1/230 3/230 6/230
Minimum supply voltage VAC
30
Nominal supply voltage VAC
230
Maximum supply voltage VAC
270
Maximum continuous power
output
W
320 1050 1900
Efficiency at rated power (at
nominal conditions)
%
> 97
Auxiliary supply voltage VDC
24 ± 20%
Auxiliary power supply VA
8
Amplitude sinusoidal/DC
continuous current
A
1 3. 3 6
Sinusoidal continuous RMS
current limit (Ic)
A
0.7 2.3 4.2
Peak current limit
A
2 x Ic
Supplied with heat sink
No #2 (fins) #4 (fins and fan)
Built-in shunt (peak power) W
400
Weight g (oz) 350 g (12.35) 490 g (17.28) 505 g (17.81)
Dimensions mm (in)
105 x 44 x 76
(4.13" x 1.73" x 3")
105 x 56 x 76
(4.13" x 2.20" x 3")
105 x 66.5 x 76
(4.13" x 2.60" x 3")
Digital in/Digital out/Analog
in
6/2/1
Mounting method Wall mount (“Bookshelf”) or DIN rail
A.4 Environmental Conditions
Feature Details
Ambient operating temperature 0 °C – 40 °C (32 °F – 104 °F)
Storage temperature -20 °C – 85 °C (-4 °F – +185 °F)
Maximum humidity 90% non-condensing
Maximum operating altitude 10,000m (30,000 feet)
Protection level IP20
Bassoon Installation Guide Technical Specifications
MAN-BASIG (Ver 1.4)
A-4
