A.8.7 Potentiometer
Feature Details
Potentiometer Format
Single-ended
Operating Voltage Range 0 ~ 5 V supplied by the Bassoon
Potentiometer Resistance 100 Ω ~ 1 kΩ … above this range, linearity is
affected detrimentally
Input Resistance 100 kΩ
Resolution 14 Bit
A.8.8 Encoder Outputs
Feature Details
Encoder output format:
A, B, Index
Differential outputs
Quadrature
Interface RS-422
Output current capability Driving differential loads of 200 Ω
Available at options
Buffered outputs of main-input
incremental encoder
Emulated encoder outputs of analog
encoder
Emulated encoder outputs of the
resolver
Maximum frequency f
MAX
: 5 MHz pulses/output
Index (marker): Length of pulse is one quadrature (one
quarter of an encoder cycle) and
synchronized to A&B
A.9 I/Os
The Bassoon has: 6 Digital Inputs 2 Digital Outputs 1 Analog Input
Bassoon Installation Guide Technical Specifications
MAN-BASIG (Ver 1.4)
A-11
