2.2 — Mechanical mounting
To Mount the ELNet LT Energy & Powermeter
1. Choose a suitable location, and prepare a
rectangular hole according to the dimensions
shown in Figure 2.1
Figure 2.1 Panel Cutout
Do not mount the ELNet LT Energy & Powermeter too
close to any main electrical conductors
Allow sufficient space to carry out maintenance to the back of
the ELNet LT Energy & Powermeter
NOTE!!
Width
90 mm
Height
90 mm
