ELNet LT - 6.6 - Communication with UniArt Software

73
Use buttons F1 &F2, to set the values
Use the buttons F3 & F4 to move the cursor
5 If required: repeat steps 1-4 to set the GATEWAY and
MASK.
6 The MAC address is set automatically however it can
be changed as well by repeating steps 1-4.
6.6 — Communication with UniArt Software
CONTROL APPLICATIONS Ltd propriety software, “UniArt” is
used to Read and Write Registers of the ELNet LT Energy
Powermeter. Each Item number in the Registers Table is a unique
field containing information. The UniArt software manages each
Item number as a parameter.
Refer to the UniArt manual how to set up parameters.
To read fields using UniArt
1 Find the reading required in the MODBUS Registers
Table
2 Note the Item Number from the Registers Table
3 Go to the correct File number
Since File capacity in UniArt is limited to 128 parameters,
the information contained in the ELNet LT fields is stored
in several files.
File number is determined by the Item number
File # 0 contains Item number 1 - 128
File
# 1 contains Item number 129 – 256
File # 2 contains Item number 257 – 384
File # 3 contains Item number 385 – 512
