5.5.2 — 2nd. Energy meter
This meter will display the total energy that was measured and accumulated in
the meter from the last “clear” of the accumulated energy data.
The accumulated energy data in this meter can be erasable (“cleared”) by the
user.
By using the sub menu you will be able to:
By using “F1” The ELNet will display the amount of the energy used for each
rate:
RT1 = Rate number 1
RT2 = Rate number 2
RT3 = Rate number 3
ALL= All rates
By using “F2” The ELNet will display the amount of the energy used for each
line:
L1 = Line number 1
L2 = Line number 2
L3 = Line number 3
ALL= All Lines
By using “F3” The ELNet will display the amount of the active, reactive and
apparent energy:
P = only active energy
Q = only reactive energy
P = only Apparent energy
By pressing and holding the “F4” button for 6 seconds ELNet will delete the
accumulated energy data:
CLR = Clear / Delete the accumulated energy data
