ELNet LT - Reset Power Peak Values; Power Demand

53
Parameter
Description Unit
P Active Power for each Line Watts
Q Reactive Power for each Line VAR
S Apparent Power for each Line VA
Σ P Total Active Power for all 3 Lines Watts
Σ Q Total Reactive Power for all 3 Lines VAR
Σ S Total Apparent Power for all 3 Lines
VA
PF Power Factor
Table 5.1 Power Readings
5.4.2 —Reset power peak values
To display /reset power peak value
1 From Main Menu scroll to Power, power factor Display.
2 Click “ENTER”. The Power, Power factor screen appears.
3 Scroll to MIN/MAX RESET and click “ENTER” in order to
clear power peak value and power factor peak values.
4 In order to clear old peak values enter password 6474.
5 Use the buttons F3 & F4 to move the cursor, to set the value
use buttons F1 &F2.
5.4.3 — Power Demand
To display Power demand within two dates
1 From Main Menu scroll to Power, power factor
Display.
2 Click “ENTER”. The Power, Power factor screen
appears.
Scroll to POWER DEMAND and click “ENTER” in order to
display power demand values.
