ELNet LT - Page 28

28
Pin
Designation
Description Remarks
V 1
Line1 Supplied Voltage
Through a 6Amp fuse
V 2
Line2 Supplied Voltage
Through a 6Amp fuse
V 3
Line3 Supplied Voltage
Through a 6Amp fuse
N
Neutral Measurement neutral Line
Pin
Designation
Description Remarks
I 1A
From Current
Transformer on Line1
Note the correct direction to
insert the lead.
Will show 0 Amp if no
voltage connected.
I 2A
From Current
Transformer on Line2
Note the correct direction to
insert the lead
Will show 0 Amp if no
voltage connected.
I 3A
From Current
Transformer on Line3
Note the correct direction to
insert the lead
Will show 0 Amp if no
voltage connected.
~
Power Supply 110 –
260 VAC
Or 110-260 VDC, external
power supply or bridged
from phase measurement
Np
Neutral Neutral of external power
supply
