Elstat ems25+ - Page 66

www.elstat.io
60
7. On the parameter loader, click the Edit Com port settings to display the dialog box below
8. Set the parameters to the values of the USB serial port of the local computer. For example:
9. Click OK
PARAMETER VALUE
COM port COM port allocated to the cradle, For example, 3.
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
