14. ems decorative trims
Note
Ensure that a matching quantity of decorative trims are ordered with controllers.
Decorative trim kits are supplied separately from ems25 series controllers in order to allow for custom installation.
Two kit sizes are available - small and large - in three varieties as described in this section
14.1 Small decorative trim kit
Available in black and black with ‘The Coca-Cola Company’ branding.
The small decorative trim kit consists of a small decorative trim, a green gasket and two side clips, as illustrated:
14.2 Fitting the small decorative trim kit
1. Fit the small decorative trim and gasket to the controller as shown:
