12. technical data ems25+
12.1 Dimensional drawings
Decorative trim kits must be ordered with ems25+ controllers.
12.2 Controller relays
ems25+ MAXIMUM IEC RATINGS @100-240VAC MAXIMUM UL RATINGS @ 120VAC
Compressor 6(6)A, p.f. 0.6 6 FLA, 36 LRA
Lights 2(2)A, p.f. 0.6 120VAC, 60Hz, 250W florescent
Evaporator fan not applicable not applicable
12.3 Temperature sensors
SENSOR INPUT RANGE (
o
C) INPUT RANGE (
o
F)
Appliance sensor -10
o
C to 23.3ºC (+/- 0.5
o
C) 14ºF to 74ºF (+/- 1ºC)
Gas cooler sensor -10
o
C to 23.3ºC (+/- 5
o
C) 122ºF to 257ºF (+/- 10ºF)
