Spare parts
74
11.1.6 Left-hand side of the machine
Fig. 36: Left-hand side
Position
Designation
Part No.
Quantity
1
Complete compressed air control
system
27000-2024
1
2
PCB pressure sensor
27000-5004
3
Valve block
51100-2030
1
4
Complete gas valve
51100-2029
4
5
CS-i/d gas valve
51100-2041
2
6
Complete control valve
51100-2032
1
7
Uni 2.x with housing
11001-3003
1
1
3
4
5
6
4
5
2
7
