Spare parts
76
11.1.6.2 Valve block, compressed air control system
Fig. 38: Valve block compressed air control system 27000-2024
Designation
Part No.
Quantity
1
5/2 way valve
66200-0140
1
2
5/3 way valve
66200-0139
1
3
Pressure regulator
60236
2
4
Pushbutton switch
66300-0158
1
5
2/2 way valve
66200-0141
1
1
2
3
4
5
