SUPPLEMENT 1

COMPUTERIZED AFM

AIRPLANE

FLIGHT

MANUAL

S1-00 ANAC APPROVED

Page 2 code 01 REVISION 4

AFM-1385

INTRODUCTION

This Supplement presents the Computerized Airplane Flight Manual

CAFM - for EMBRAER 170 and EMBRAER 175 performance

calculation.
