RRP: ED-DCX-4S-B chassis
133
Removal and Replacement Procedures (RRPs)
4. Remove the control processor blades (CP8) (“RRP: Control
processor blade (CP8)”).
5. Remove the power supplies or filler panels (“RRP: Power
supply”).
6. Remove the blower assemblies (“RRP: Blower assembly”).
7. Remove the WWN bezel (logo plate) and WWN cards (“RRP:
WWN card”).
Installing the replacement chassis
Use safe lifting practices when moving the product. (C015)
Note: A fully populated ED-DCX-4S-B (four PB-DCX-48P port cards, 192
ports) weighs approximately 68 kg (150 lbs) and requires a hydraulic or
assisted lift to install it.
Note: If the ED-DCX-4S-B is installed in a cabinet, ensure that the cabinet is
balanced and secured mechanically and that the removal and installation
procedure will not compromise cabinet stability.
1. If the chassis is in a cabinet, remove it from the cabinet, remove
the rack mount hardware, and save the hardware for use with the
new chassis.
2. Place the chassis on a lift or on the shipping pallet provided with
the original chassis.
3. Unpack the new chassis:
a. Cut the bands that encircle the packaging.
b. Remove the lid and the kits and foam from the top of the
chassis.
c. Lift the cardboard box off the chassis and remove the
plastic bag from around the chassis.
Save the packing materials for use when returning the old
chassis.
d. Leave the chassis on top of the plastic shipping tray if the
chassis must be transported to the installation location.
