EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Specifications
System blade and FRU weights
Table 18 lists the weights of the compatible blades and FRUs.
Note: Note: The blade identifiers in parenthesis in Table 18 reflect the
Brocade blade model names. These are the names that will appear in the
various CLI output and logs.
Table 18 System FRU weights
FRU Weight
CP blade (CP8) 3.0 kg (6.6 lb.)
CR blade (CR4S-8) 3.27 kg (7.2 lb.)
PB-DCX-16P (FC8-16) port blade 3.0 kg (6.6 lb.) without media
PB-DCX-32P (FC8-32) 3.27 kg (7.2 lb.) without media
PB-DCX-48P (FS8-48) port blade 3.36 kg (7.4 lb.) without media
PB-48K-10G-6 (FC10-6)port blade 3.1 kg (6.8 lb) without media
PB-48K-AP4-18 (FA4-18) application blade 3.36 kg (7.4 lb) without media
PB-48K-18i (FR4-18i) application blade 3.36 kg (7.4 lb) without media
PB-DCX-16EB (FS8-18) encryption blade 5.5 kg (12.0 lb)
Port card filler panel 1.5 kg (3.2 lb)
Power supply 2.45 kg (5.4 lb.)
Blower assembly 5.73 kg (12.6 lb.)
WWN bezel 0.3 kg (0.6 lb)
Vertical cable management fingers 0.45 kg (1.0 lb.)
Chassis door 2.09 kg (4.6 lb.)
