RRP: Chassis door
87
Removal and Replacement Procedures (RRPs)
RRP: Chassis door
Note: The chassis door must be installed to ensure the ED-DCX-4S-B meets
EMI and other regulatory certifications. Additionally, if ICL cables are not
used, EMI plugs must be inserted in the ICL cable ports to meet certification
standards.
Time and items
required
The replacement procedure for the chassis door takes less than five
minutes.
Removing a chassis
door
Support the door to prevent it from falling. Pull and remove the door.
Figure 17 RRP: Chassis door
