Determining the status of a port, application, or encryption blade
63
Monitor System Components
Determining the status of a port, application, or encryption
blade
1. Check the LEDs on the blade.
• Figure 5 on page 64 illustrates the PB-DCX-16P port blade.
• Figure 6 on page 65 illustrates the PB-DCX-32P port blade.
• Figure 7 on page 66 illustrates the PB-DCX-48P port blade.
• Figure 8 on page 67 illustrates the PB-48K-10G-6 port blade.
• Figure 9 on page 68 illustrates the PB-48K-18i application
blade.
• Figure 10 on page 69 illustrates the PB-48K-AP4-18 application
blade.
• Figure 11 on page 70 illustrates the PB-DCX-16EB encryption
blade.
The LED patterns may temporarily change during POST and
other diagnostic tests. For information about how to interpret the
LED patterns, see Table 4 on page 71.
2. Check the blade status by entering slotShow.
