EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Specifications
Environmental requirements
Table 19 lists the environmental operating ranges for the
ED-DCX-4S-B. The requirements for non-operating conditions are
also provided for acceptable storage and transportation
environments.
Note: The 10° to 40° Celsius range applies to the ambient air temperature at
the air intake vents on the nonport side of the ED-DCX-4S-B.
The temperature inside the ED-DCX-4S-B can be up to 75
° Celsius during
operation. If the internal temperature range exceeds the operating ranges of
the components, the LEDs, error messages, and Fabric Watch alerts will
indicate a problem. Use the tempShow command or Fabric Watch commands
to view temperature status.
Table 19 Environmental requirements
Condition Acceptable range during operation Acceptable range during nonoperation
Ambient temperature 10
° to 40° C outside switch
(50
° to 104° F)
-40
° to +70° C outside switch
(-40
° to 158° F)
Humidity 5% to 85% RH noncondensing, at
40° Celsius, with maximum gradient of 10%
per hour
10% to 93% RH noncondensing, at 70
°
Celsius
Altitude Up to 3 km (10,000 ft.)
above sea level
0 to 12 km (40,000 ft.)
above sea level
Shock 20G, 6ms duration, half-sine wave 33G, 11ms duration, half-sine wave
Vibration 0.5G p-p, 5-500 Hz at 1.0 octave/minute 2.0G p-p, 5-500 Hz at 1.0 octave/minute
Air flow 350 cu ft/min.
(0.00059 cu m/hr)
None required
Heat dissipation 841 Watts or 2869 BTU/hr
(Four PB-DCX-48P blades, two CP8 blades,
and two CR4S-8 blades)
Not applicable
