EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Port Side Exhaust Kit Installation Procedure
Table 26 Hardware for Port-Side Exhaust Kit for 27 to 31 in. (68.58 to 78.74 cm)
cabinets
Item Description Quantity
ATop rail 1
BDuct 1
C Shelf 1
D 10-32 x .5 in. (1.27 cm) Phillips screw (blue Loctite on threads) 12
E 10-32 x .63 in.(1.60 cm) Phillips screw with square cone washer 12
F 10-32 clip nut for cabinets that have rails with round holes 8
G 10-32 retainer nut for cabinets that have rails with square holes 8
H Alignment washer for cabinets that have rails with square holes 12
I 6-32 x .25 in. (.635 cm) Phillips screw 2
