ED-DCX-4S-B blades
23
Hardware Overview
Note: The blade identifiers in parenthesis in Table 1 reflect the Brocade blade
model names. These are the names that will appear in the various CLI output
and logs.
Fibre Channel
application blade
PB-48K-AP4-18
(FA4-18)
The FR4-18 blade has 16 (1-, 2-, and 4-Gbps) physical ports supporting
Fibre Channel Application Services and 2 10/100/1000 BaseT Ethernet
copper interfaces supporting blade management. This application blade
is compatible with the ED-48000B Director, the ED-DCX-B and the
ED-DCX-4S-B.
Fibre Channel router
blade
PB-48K-18i
(FA4-18i)
The PB-48K-18i blade has 16 physical Fibre Channel SFP ports
supporting Fibre Channel Routing Services and 2 physical Gigabit
Ethernet (GbE) SFP ports supporting Fibre Channel Over IP (FCIP). The
two physical GbE ports can support up to 16 virtual E_Ports. This
application blade is compatible with the ED-48000B Director, the
ED-DCX-B and the ED-DCX-4S-B.
Storage encryption blade PB-DCX-16EB
(FS8-18)
The PB-DCX-16EB blade enables data cryptographic
(encryption/decryption) and data-compression capabilities. It has 16
Fibre Channel optical SFP ports. This blade requires the use of a 220
VAC power supply in the ED-DCX-4S-B. This application blade is
compatible only with the ED-DCX-B and the ED-DCX-4S-B.
Table 1 Blades available for the ED-DCX-4S-B (page 2 of 2)
