EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Monitor System Components
Port Status No light (LED is off) Port has no incoming power, or
there is no light or signal carrier
detected.
Verify that the power LED is on,
check the transceiver and cable.
Polling is in progress. Allow 60 seconds for polling to
complete.
Connected device is configured in
an offline state.
Verify the status of the connected
device.
Steady green Port is online (connected to an
external device) but has no traffic.
No action required.
Slow-flashing green (on 1
second, then off 1 second)
Port is online but segmented,
indicating a loopback plug or cable
or an incompatible switch.
Verify that the correct device is
attached to the ED-DCX-4S-B.
Fast-flashing green (on 1/4
second, then off
1/4 second
Port is in internal loopback
(diagnostic).
No action required.
Flickering green Port is online, with traffic flowing
through port.
No action required.
Steady amber Port is receiving light or signal
carrier, but it is not online yet.
Reset the port from the workstation
using the portEnable or
portCfgPersistentEnable
command.
Slow-flashing amber (on 2
seconds, then off 2 seconds)
Port is disabled due to diagnostic
tests or portDisable or
portCfgPersistentEnable
command.
Reset the port from the workstation
using the portEnable or
portCfgPersistentEnable
command.
Fast-flashing amber
(on 1/2 second, then
off 1/2 second)
Transceiver or port is faulty. Change the transceiver or reset
the switch from the workstation.
Alternating green/amber Port is bypassed. Reset the port from the workstation
using the portEnable or
portCfgPersistentEnable
command.
Table 4 Port, application, and encryption blade LED descriptions (continued)
LED purpose Color Status Recommended action
