RRP: Port, application, and encryption blades
93
Removal and Replacement Procedures (RRPs)
• For PB-48K-10G-6 port blade, and PB-48K-AP4-18, and
PB-48K-18i application blades: Unscrew the two thumb
screws from the top and bottom ejectors on the blade using the
Phillips screwdriver. Lever both ejectors open simultaneously
to approximately 45 degrees and pull the blade out of the
chassis.
12. If the blade is not being replaced by another blade, install a filler
panel (“RRP: Blade filler panel”).
Figure 19 RRP: Port, application, or encryption blade (PB-DCX-48P port blade
shown)
