RRP: Port, application, and encryption blades
95
Removal and Replacement Procedures (RRPs)
• For PB-48K-10G-6 port blade, and PB-48K-AP4-18, and
PB-48K-18i application blades: Tighten the thumb screw
inside each handle using the Phillips screwdriver.
5. Perform the appropriate following action based on the type of
blade:
• For PB-DCX-16P, PB-DCX-32P, PB-DCX-48P port blades, and
PB-DCX-16EB encryption blade: Skip to step 6.
• For PB-48K-10G-6 port blade, and PB-48K-AP4-18, and
PB-48K-18i application blades: Turn the blade on by sliding
the slider switch in the left ejector to the left, covering the
thumb screw.
6. Verify that the power LED on the port blade is displaying a
steady green light. If it does not turn on, ensure that the blade is
firmly seated.
7. Install the SFP or XFP (PB-48K-10G-6 only) transceivers and
cables in the port blade.
8. Group and route the cables through the vertical cable fingers.
9. Replace the chassis door (“RRP: Chassis door”).
