DPSI RV Mini Family Operating Instructions Version 1.0
Page 24 of 54
Pin-Switch-Actuator in DPSI RV Mini:
The pin, put into the "ON" socket (red) turns the DPSI RV Mini on.
Putting it into the "OFF" (black) socket turns the DPSI RV Mini off.
Even if the pin gets lost a powered system remains on.
A DPSI RV Mini only can be turned off if the pin is put into the OFF
socket (in other words swapped from red to black)!
DPSI RV pin-switch-actuator:
Of course, two pins must not be put into each of the sockets at the
same time although this does not damage the DPSI RV Mini. In this
case, the set would be turned off and the batteries would be
discharged slowly with approx. 12mA. In the powered state the pin
should always remain in the ON socket!
Hint:
Should the pin get lost, a 2mm wire or 2mm screw suffices by putting it into the
corresponding socket.
