Wet calibration - 12-point piece-wise linearization Equation 5-3:


= 


Equation 5-3
V
WetCal
wet-calibration gas flow velocity (m/s) (AvgFlow)
V
DryCal
dry-calibration gas flow velocity (m/s) (DryCalVel)
LinearMeterFctr
linear meter factor (dimensionless) (LinearMeterFctr)
where
Piece-wise linearization calibration
The linear meter factor is determined by the PWL inputs, the flow direction, and the dry-
calibration gas flow velocity. If set to Piece-wise Linear" then the piece-wise linearization
flow rate and meter factor parameters are used to calculate the meter factor to be applied.
Calibration - Meter Factor: Piece-wise linearizationFigure 5-3:
Configurations
