Fixed gas composition data points (continued)Table 5-8:
Gas composition data points
MoleFractionEthane
MoleFractionPropane
MoleFractionIsoButane
MoleFractionNButane
MoleFractionIsoPentane
MoleFractionNPentane
MoleFractionNHexane
MoleFractionNHeptane
MoleFractionNOctane
MoleFractionNNonane
MoleFractionNDecane
MoleFractionH2S
MoleFractionHelium
MoleFractionWater
MoleFractionOxygen
MoleFractionArgon
Live (GC) gas property data
The purpose of this section is to give a brief overview of the gas property data read from a
GC. Refer to for information on configuring the Daniel 3410 Series Gas Ultrasonic Flow
Meter (using the Daniel MeterLink program) for communicating with a Daniel GC.
If the gas components are read from the GC, then the GC-reported heating value is
readable via the HeatingValueGC data point. Note that type of heating value to be read
from the GC must be specified via the GCHeatingValueType data point as either Btu-Dry,
Btu-Saturated, or Btu-Actual. So that the correct GC register is read. Also, the heating
value unit must be specified via the GCHeatingValueUnit data point as either Btu/ft
3
,
kJ/m
3
, kJ/dm
3
, MJ/m
3
, kCal/m
3
, or kWh/ m
3
. The GC-reported gas composition is readable
via the data points listed in Table 5-9 below:
GC-reported gas composition data pointsTable 5-9:
GC reported composition data points
N2GC
CO2GC
H2GC
COGC
MethaneGC
EthaneGC
